Product Details:
|
| Adhesive Type: | Cold Weather Solvent Acrylic Adhesive | Service Temperature Range: | -30 ~ +120 °C |
|---|---|---|---|
| Backing Thickness: | 43um | Cut Roll Width: | 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4"). |
| Scrim: | 5mmx5mm | Backing Material: | Scrim Reinformed Al Foil 18um |
| Releasing Paper: | White Releasing Paper | ||
| High Light: | 43 micron Foil Scrim Tape,Foil Scrim Tape Cold Weather,Cold Weather reinforced aluminium foil tape |
||
Cold Weather Tape FS1825B/CW
Scrim Reinforced Aluminium Foil Adhesive Tape With Releasing Paper Used Under Cold Temperature
High Quality Foil-Scrim Tape high flexibility with reinforcement
PRODUCT DESCRIPTION
Foil-Scrim backing (Foil: 18u / 2-way Scrim: 5mmx5mm), combined with high performance solvent acrylic adhesive, protected by an easy-release silicone release paper.
FEATURES
• Foil-Scrim backing provides excellent reflection of both heat and light.
• Cold weather adhesive with moderate adhesion and holding power offers reliable and durable Foil-Scrim Facing joints and seams sealing in HVAC ductwork application.
• Good aging resistance both indoors and out doors.
• Low moisture vapor transmission rate offers excellent ealing and patching performance.
• Service Temperature range from -30 ~ +120 °C (-22~ +248 °F).
TYPICAL PHYSICAL PROPERTIES
| PROPERTIES | METRIC | TEST METHOD |
| Backing Thickness | 0.043mm | PSTC-133 |
| Total Thickness | 0.083mm | PSTC-133 |
| Tensile strength | 100N/25mm | PSTC-131 |
| Elongation | 3% | PSTC-131 |
| Adhesion to Steel | ≥15 N/25mm | PSTC-101 |
| Ball Tack | 5cm | PSTC-6 |
| Service Temperature | -20 ~ +80 °C | ------------ |
| Applying Temperature | +10 ~ 40 °C | ------------ |
TYPICAL APPLICATIONS: HVAC industry for joining and sealing Alum.-Glass Facing laminated fiberglass blanket / duct board/ pipe section joints and seams; joining and sealing flexible air duct seams and connections. May also be used for other industrial uses requiring a tape with these characteristics and benefits.
PRODUCT FORM & SIZE AVAILABLE
Cut Roll width: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4").
Roll width:1000mm,1200mm
Length: Log roll: 45 / 50m Jumbo Roll: 500m / 750m
